Point d’accès CPE Outdoor TP-Link CPE610
| CARACTERISTIQUES MATERIELLES | |
| Processeur | 560MHz CPU, MIPS 74Kc |
| Mémoire | 64MB DDR2 RAM,8MB Flash |
| Interface | 1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button |
| Alimentation | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC |
| Consommation | 8.8 W Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable. |
| Dimensions (LxPxH) | 366 x 280 x 207 mm |
| Gain de l’antenne | 23dBi |
| Faisceau d’antenne | 9°(Azimuth), 7°(Elevation) |
| Protection | 15KV ESD Protection 6KV Lightning Protection |
| Enceinte | Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design |
| CARACTÉRISTIQUES WIFI | |
| Standards WiFi | IEEE 802.11a/n |
| Protocole propriétaire | TDMA Mode (with Pharos MAXtream enabled) |
| Débit WiFi | Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic) |
| Fréquence WiFi | 5.15~5.85GHz |
| Puissance de transmission | Max. 25dBm (Adjustable power by 1dBm) |
| CARACTERISTIQUES LOGICIELLES | |
| Configuration réseau | WAN: Static/Dynamic/PPPoE/L2TP/PPTP LAN: Static/Dynamic/DHCP Forwarding: ALG/UPnP/Virtual Server/Port Trigger Security: SPI Firewall/ Ping Forbidden/DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding |
| Configuration WiFi | Pharos MAXtream TDMA Technology Selectable Channel Width: 5/10/20/40MHz Auto Channel Selection Transmit Power Control Dynamic Frequency Selection(DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging(AP Mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia |
| Administration | Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server |
| Outils système | Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute |
| Optimisations du niveau système | Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog |
| CARACTÉRISTIQUES POE | |
| Dimensions (LxPxH) | 4.3 x 2.2 x 1.3 in |
| Interfaces | 1 AC Jack with Earth Ground 1 10/100Mbps Shielded Ethernet Port (Power + Data) 1 10/100Mbps Shielded Ethernet Port (Data) |
| Bouton | Remote Reset Button |
| Témoin lumineux d’états de puissance | Green |
| Entrée | 100-240VAC, 50/60Hz |
| Sortie | 24VDC, 0.6A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet) |
| Efficacité | >84.29% |
| Certifications | CE/FCC |
| AUTRES | |
| Certification | FCC, RoHS |
